Khoom Description
FG-1100JZ tsis siv neeg lub thawv folding thiab gluing tshuab yog dav siv rau kev ua cov ntawv thawv xws li cov kab ncaj nraim corrugated wine thawv hauv ntim thiab tshuab luam ntawv.
Tshuab qauv: daim ntawv pub ib feem, kho ib feem, folding ib feem (sab saum toj tsav tsheb), tso zis ib feem, pneumatic conveyor ib feem
Technical Parameters
1) Daim ntawv siv tau: 200-800GSM cardboard, E, F corrugated cardboard (micro corrugated).
2) Ceev: siab tshaj plaws linear ceev: 400 meters / feeb.
3) Lub thawv hom: sab pasting
4) Tag nrho lub zog: 10.5kW
5) Lub cev muaj zog: 7.5 kW
7) Tshuab loj (L × W × H): 10000 * 1800 * 1600mm
8) Cua qhov yuav tsum tau muaj: 1.1KW 60L cua compressor
KEV PAB
- Cua suction feeder rau kev khiav haujlwm du
- Txhua pawg ntawm phau ntawv qhia tuaj yeem txav mus rau kab rov tav, thiab cov log tsheb coj cov ntaub ntawv siv;
- Muaj baffles ntawm sab laug thiab sab xis, tso cai rau cov khoom tawm ntawm daim ntawv vertically;
- Nruab nrog ob daim ntawv riam
- Vibrating lub cev muaj zog lossis pneumatic vibrator tuaj yeem xaiv tau dawb
- Ib qho yooj yim hloov rau kev pub mis
- Xws li kev ywj pheej lub cev muaj zog hloov kho kom ceev.
ALIGNMENT
- Nws muaj ob pawg ntawm pawg thawj coj saib;
- Txhua pawg ntawm daim phiaj qhia yog nruab nrog ib txoj siv tensioned;
- Muaj ib kab ntawm kev nyuaj siab bearings nyob rau sab saum toj;
- Qhov kev ua tsis sib thooj ntawm lub thawv tuaj yeem raug kho kom ntseeg tau tias daim ntawv taug kev sib npaug mus rau ntu tom ntej.
Sab saum toj tsav tsheb thiab folding seem
- Lub folding ntug tswj cov cuab yeej ua kom qhov tseeb ntawm qhov loj ntawm qhov khi.
- Sab laug thiab sab xis ob txhais tes tshwj xeeb pwm steel turbulent riam zoo tswj lub folding ntawm lub qhov ncauj qhov ncauj.
- Qhov sib ntxiv ntawm kev thawb-ups ntawm sab sauv pab tswj qhov tshwm sim ntawm txiab thiab ntses tail marks tom qab tsim.
- Ib tug tig nrog ib tug dav ntawm 50 hli kom smoother thiab ntau txawm folding ntawm lub thawv.
Cov zis seem:
- Plaub txoj siv tawv los ntawm ob pab pawg ntawm cov ntawv qhia rau sab sauv thiab qis.
- Qhov ntev ntawm kev sib kis sab saud thiab qis tuaj yeem hloov kho raws li cov duab ntawm lub thawv.
- Tsis tu ncua automate lub boxing txheej txheem los xyuas kom meej tias cov thawv yog zoo huv si nkag mus rau hauv lub tsheb thauj mus los department.
- Nruab nrog lub ntsuas ntsuas ntsuas, lub txee tswj lub thawv tawm thiab kev txheeb xyuas.
Pneumatic Conveyor Tshooj:
- Siv ib qho kev ywj pheej 1000mm dav thiab 4mm tuab txoj siv.
- Mos thiab nruab nrab, nws yuav tsis ua rau cov khoom tiav.
- Tag nrho lub tsheb thauj mus los tuaj yeem txav mus los.
- Kev sib npaug siab ua kom muaj kev thauj mus los zoo, ua kom zoo zoo.
- Qhov ceev ntawm lub conveyor seem kho tau raws li tus tswv lub cev muaj zog ceev nrog kev pab ntawm cov khoom siv sensor.
- Kev ceev thiab tsis siv neeg hloov ceev kuj muaj.
